Description

Main Part Number: 100144.0
• Replacement/Related Numbers: 6701201, 42623
• Product Name: Ball Joint / Ball Joint
• Product Description: This is a ball joint typically used to connect a hydraulic cylinder to a lever or other linkage mechanism. It serves as a flexible connection point, allowing limited movement in multiple directions while transmitting push and pull forces.
• Common Locations: Typically located at the end of hydraulic actuators, such as those used for lifting or adjusting harvesting tables, adjusting threshing drums, and adjusting screen boxes.

Main Functions and Features
1. Flexible Connection: Provides universal rotation to compensate for misalignment during installation and operation.
2. Force Transmission: Converts the linear motion of the hydraulic cylinder into oscillating or adjusting motion of the mechanical component.
3. Durable and Wear-Resistant: Typically made of high-strength steel, the ball joint is hardened and equipped with a wear-resistant bushing or bearing to ensure long service life. 4. Sealed and Dust-Proof: A dust cover prevents dust, dirt, and moisture from entering the ball socket, maintaining lubrication and reducing wear.

Applicable Models
This ball joint is widely used in a variety of Claas combine harvesters and other agricultural machinery. The following are some of the main applicable models:
Combine Harvesters
• LEXION 700 Series:
◦ LEXION 770
◦ LEXION 760
◦ LEXION 750
• LEXION 600 Series:
◦ LEXION 670
◦ LEXION 660
◦ LEXION 650
◦ LEXION 640
• LEXION 500 Series:
◦ LEXION 580
◦ LEXION 570
◦ LEXION 560
◦ LEXION 550
• LEXION 400 Series:
◦ LEXION 480
◦ LEXION 460
• DOMINATOR Series:
◦ DOMINATOR 116, 118, 120
◦ DOMINATOR 106, 108, 110
• MEGA Series:
◦ MEGA 208, 218, 228
◦ MEGA 360, 370, 380
• TUCANO Series:
◦ TUCANO 430, 450, 470, 490
◦ TUCANO 320, 330, 340
• AVERATO Series:
◦ AVERATO 220, 230, 240
• SCORPION Series:
◦ SCORPION 7030, 7040, 7050
◦ SCORPION 6030, 6040, 6050
Forage Harvesters
• JAGUAR 900 Series:
◦ JAGUAR 970, 980, 990
• JAGUAR 800 Series:
◦ JAGUAR 870, 880, 890
• JAGUAR 700 Series:
◦ JAGUAR 770, 780
Tractors and Other Machinery
• Some models of the Chrysler Axion or Arion series tractors may also use similar ball joints for front loaders or three-point hitches, but their primary application is harvesters.
