Description
Product Overview
Attributes
Description
Part Number
47130636
Part Name
Lifting Arm Assembly
Color
Gray
Length
635 mm / 780 mm L
Main Application
Header of Combine Harvester
Important Note: A length designation of “635/780 mm L” usually indicates that the lifting arm is adjustable or telescopic, or that its length changes depending on the installation configuration to accommodate different header or lifting requirements.
Main Functions and Description
This lifting arm assembly is a key hydraulic component connecting the main unit of a combine harvester and the front header (such as a grain platform, corn header, etc.). Its main functions are:
• Lifting and lowering the header: Achieving the raising and lowering of the header through hydraulic cylinder control.
• Supporting the header weight: Bearing most of the header’s weight during transport and operation.
• Maintaining header stability: Ensuring the header maintains a stable ground clearance when operating on undulating terrain.
• Quick connection and disconnection: This is an important component of the CASE IH header quick connection system.
Applicable Models
This part (47130636) is primarily suitable for the following CASE IH axial-flow drum combine harvester series, used to connect to various models of their front headers:
1. CASE IH 1400 Series
• CASE IH 1440
• CASE IH 1460
• CASE IH 1480
2. CASE IH 1600 Series
• CASE IH 1640
• CASE IH 1660
• CASE IH 1680
3. CASE IH 2100 Series
• CASE IH 2166
• CASE IH 2188
4. CASE IH 2300 Series
• CASE IH 2366
• CASE IH 2388
5. CASE IH 2500 Series
• CASE IH 2577
• CASE IH 2588
